Asciugatrice a gas inclinabile in avanti Kingstar: un'asciugatrice ad alta efficienza e a risparmio energetico

Gli essiccatori sono tra le apparecchiature a maggior risparmio energetico impianti di lavanderia , e sono anche le attrezzature spesso trascurate dagli impianti di lavanderia. Currently, many dryers have a phenomenon where energy consumption is high, and the efficiency is low. Gli asciugamani lavati con la lavatrice da 100 kg non possono essere asciugati in un solo passaggio attraverso l'asciugatrice da 100 kg. They often need to be dried in two batches, which greatly reduces the efficiency.

Presenteremo il Kingstar 100kg essiccatore a gas ribaltabile in avanti SDR-2100TG, un vero essiccatore a risparmio energetico. Diamo prima un’occhiata a una serie di dati comparativi.

Confronto dei consumi
A laundry factory has an average daily washing volume of 2,000 sets. It uses Kingstar SHS-2100 industrial washing machines for washing. The towels that need to be dried every day are 2000*3.5 kilograms per set *40%=2800 kg.

Let’s take a look at the energy consumption comparison between the Kingstar 100kg gas dryer SDR-2100TG and the ordinary steam dryer.

● Tintrice a vapore ordinaria da 100 kg

Consumo di vapore per lotto: 160 kg

Peso degli asciugamani asciutti: 60 kg

Consumo di vapore per asciugare 1 kg di asciugamani: 2,7 kg

● Asciugatrice a gas Kingstar da 100 kg SDR-2100TG

Consumo di gas per lotto: circa 10 metri cubi

Peso degli asciugamani asciutti: 100 kg

Gas consumption to dry 1kg of towels: 0.1 cubic meters

Costo Consumo
● Tintrice a vapore ordinaria da 100 kg

Steam consumption for drying 2,800 kg of towels: 2.7 kg/kg × 2,800 = 7,560 kg. (7,56 tonnellate).

Calculated at the domestic steam price of RMB 260 per ton, the daily steam cost is RMB 1,965.6.

● Asciugatrice a gas Kingstar da 100 kg SDR-2100TG

The natural gas consumption for drying 2,800 kg of towels: 0.1 m³/kg × 2,800 = 280 m³.

Calculated at the domestic natural gas price of RMB 4 per m³, the daily natural gas cost is RMB 1,120.

Attraverso il confronto sopra riportato, utilizzando l'essiccatore a gas Kingstar SDR-2100TG è possibile risparmiare in media circa 845,6 RMB al giorno, circa 25.368 RMB al mese e quasi 300.000 RMB all'anno. L’effetto sul risparmio sui costi è molto evidente

Vantaggi dell'asciugatrice a gas Kingstar
● Efficienza

Kingstar 100kg Forward-Tilted Gas Dryer SDR-2100TG can be paired with the Kingstar Industrial Washer SHS-2100 for one-to-one drying. Ogni ciclo di asciugatura dura circa 40 minuti.

In contrast, standard steam dryers typically require two separate batches for the same load, and each batch takes over 40 minutes to dry.

As a result, the Kingstar 100kg Forward-Tilted Gas Dryer SDR-2100TG offers twice the efficiency of standard steam dryers. Grazie alla maggiore efficienza di Kingstar, è possibile configurarlo in quantità minori, il che contribuisce a ridurre effettivamente i costi e a migliorare l’efficienza degli impianti di lavanderia.

● Design intelligente e facile da usare

Oltre ai vantaggi in termini di efficienza e consumo energetico, l'essiccatore a gas Kingstar SDR-2100TG presenta anche design più intelligenti e intuitivi per un funzionamento e un utilizzo più semplici.

- It adopts a full-colour high-definition touch screen, and can store 99 drying programs. All programs are editable, and the operation interface is clear and intuitive for hassle-free operation.

- The large-diameter double door design saves space and helps with the loading and unloading of linen. The forward-tilted discharge function makes automatic linen discharge. This reduces labour intensity for employees and prevents linen from being damaged.

- The inner drum volume of the Kingstar dryer is designed with a load ratio of 1:20. The large-capacity inner drum allows linen to fully expand inside and improve drying efficiency.

- The inner drum is made of high-quality 304 stainless steel.

- The outer cylinder is insulated with wool, so that the dryer heats up quickly and prevents temperature loss during operation. This improves drying efficiency and reduces energy consumption.

- It has temperature and humidity control technology to real-time monitor the drying degree of towels. Even towels dried by gas heating can maintain fluffiness and softness.

- It has a spray system, temperature switch, and air pressure detection device. They fully ensure safety during equipment operation.

Conclusione
The above is a comprehensive introduction to the Kingstar Forward-Tilted Gas Dryer. If you are looking for a high-efficiency and energy-saving dryer, please contact us for more detailed information.
